Product Features:

1. Precise Timing: Supports multi-level timing adjustment with accurate time control.

2. Component Synergy: Forms a closed-loop control system with PLC (Programmable Logic Controller), pneumatic valve groups, cylinders, and sensors as the core components.

3. Flexible Adaptability: Allows setting of multiple timing modes, is compatible with pneumatic components of different specifications, and suits application scenarios across various industries.

4. Suitable for Practical Training: Features a modular structure that supports disassembly, assembly, and mode switching, meeting the needs of teaching and practical training.

Product Applications:

Widely used in production practical training in industries such as machinery manufacturing, automobile assembly, and food processing, as well as in skill improvement training for maintenance personnel of pneumatic systems.

Warranty Period: One-Year Warranty

Configuration List:

Experimental Projects：

1.MicroLogix 1400-PTC01：Sequential Start/Stop of Cylinders

·Main Configuration Description: Includes PLC, TN10X30S, TN10X70S, and accessories (such as sensors, solenoid valves, etc.).

·Precise Sequential Control Logic: The PLC drives the TN10X30S and TN10X70S cylinders to complete telescopic actions (such as extending first then retracting, alternating actions, etc.) according to the preset sequence through a preprogrammed routine. The action sequence can be flexibly adjusted via the source code to meet different training requirements.

2.MicroLogix 1400-PTC02：Single-Station Material Handling

·Main Configuration Description：It includes PLC, TN10X30S, HLS12X50S, MHY2-20D, and accessories (such as sensors, solenoid valves, etc.).

·Precise Single-Station Material Handling: The PLC coordinates three types of executive components—TN10X30S (for telescopic positioning), HLS12X50S(for clamping/releasing materials), and MHY2-20D (for driving displacement)—according to the preset logic. It completes the automated handling process of "material positioning → clamping materials → driving displacement → releasing materials → resetting for standby", with precise and controllable action timing.

3.MicroLogix 1400-PTC03：Multi-Action Process Control

·Main Configuration Description: Includes PLC, TN10X30S, TN10X70S, HLS12X50S, MHY2-20D, and accessories (such as sensors, solenoid valves, etc.).

·Coordinated Process Execution of Multi-Actions: The PLC coordinates the orderly linkage of four types of cylinders according to preset logic, completing standardized processes such as "material displacement → clamping and positioning → short-stroke transfer and conveying → releasing and unloading → material reset". The action sequence and execution rhythm are precisely controllable, which can adapt to the multi-step automated operation requirements in different scenarios.

Price List: (Prices are subject to consultation)
