6ES7223-1HF22-0XA0 SIMATIC S7-200, DIGITAL I/O

SIMATIC S7-200, DIGITAL I/O EM 223, FOR S7-22X CPU ONLY, 4 DI / 4 DO RELAY, 5-30 V DC, 250 V AC

Supply voltage

Load voltage L+

Rated value (DC)

24 V

permissible range, lower limit (DC)

5 V

permissible range, upper limit (DC)

30 V

Load voltage L1

Rated value (AC)

230 V; 24 V AC to 230 V AC

permissible range, lower limit (AC)

5 V

permissible range, upper limit (AC)

250 V

Input current

from backplane bus 5 V DC, max.

40 mA

from coil current, max.

9 mA; for each output on signal "1"

from sensor current supply or external current supply (24 V DC), max.

72 mA

Power losses

Power loss, typ.

2 W

Digital inputs

Number of digital inputs

Input voltage

Type of input voltage

AC/DC

Rated value, DC

24 V

for signal "0"

0 to 5 V

for signal "1"

15 to 30 VDC

Input current

for signal "1", typ.

4 mA

Input delay (for rated value of input voltage)

for standard inputs

at "0" to "1", max.

4.5 ms

Digital outputs

Number of digital outputs

4; Relays

Short-circuit protection

Output voltage

for signal "0", max.

0.1 V; with 10 kOhm load

for signal "1", min.

L+/L1

Output current

for signal "1" rated value

2000 mA

Aggregate current of outputs (per group)

all mounting positions

maximum current per conductor/group

8 A

Relay outputs

Number of operating cycles, max.

10000000; mechanically 10 million, at rated load voltage 100,000

Switching capacity of contacts

with inductive load, max.

0.75 A; per output

on lamp load, max.

200 W; 30 W with DC, 200 W with AC

with resistive load, max.

0.75 A; per output

Cable length

Cable length, shielded, max.

500 m

Cable length unshielded, max.

150 m

Encoder

Connectable encoders

2-wire sensor

Yes

Permissible quiescent current (2-wire sensor), max.

1 mA

Galvanic isolation

Galvanic isolation digital inputs

Yes; Optocoupler

between the channels, in groups of

Galvanic isolation digital outputs

Yes; Relays

between the channels, in groups of

Isolation

Isolation checked with

500 V AC

Connection method

Plug-in I/O terminals

Yes

Dimensions

Width

46 mm

Height

80 mm

Depth

62 mm

Weights

Weight, approx.

160 g
